SKU: FM2G120-OK-G

Forno Bravo Modena OK Gas Fired Commercial Pizza Oven

$12,900.00

Shipping calculated at checkout

Size: Modena2G 120 48”

Available Now!

Build a commercial hearth around the Forno Bravo Modena OK oven kit. Its modular refractory components provide the insulated cooking core while allowing your installer to create a noncombustible support and exterior suited to the kitchen.

Key Features

  • Modular oven-core construction allows assembly at the installation site.
  • Refractory dome and firebrick floor retain heat for hearth-style cooking.
  • Insulation and an insulated door with thermometer are included with the core kit.

Specifications

  • Manufacturer: Forno Bravo
  • Modena2G 120 48” — SKU: FM2G120-OK-G
  • Modena2G 140 56” — SKU: FM2G140-OK-G
  • Modena2G 160 56” x 64” — SKU: FM2G160-OK-G
  • Modena2G 180 56” x 72” — SKU: FM2G180-OK-G
  • Available models: Modena2G120,140,160 and 180.
  • Gas-equipped listing; confirm the exact propane or natural-gas burner configuration.
  • Dome thickness: 4 inches; firebrick floor: 2½ inches.
  • Insulation: 4 inches at the sides, 6 inches over the dome and 4 inches under the floor.
  • A finished stand, hearth and exterior enclosure are not included in the modular core kit.

Dimensions

  • Modena2G120: nominal 48-inch round cooking space; Modena2G140: nominal 56-inch round cooking space.
  • Modena2G160: nominal 56 × 64-inch cooking space; Modena2G180: nominal 56 × 72-inch cooking space.
  • These model dimensions are not the finished footprint; allow for the landing, insulation, enclosure and installation clearances.

Compatibility & Installation

  • Build the noncombustible support and exterior according to the manufacturer installation plans.
  • Have the foundation designed for the complete oven, insulation, enclosure and venting load.
  • Arrange the approved chimney or hood system for the actual site before starting construction.
  • Commercial gas-burner installations are for indoor use; confirm fuel type, electrical requirements, burner airflow and service access with a qualified installer.
  • For the SCBMOD option, follow the supplied burner instructions for gas-only or limited gas/wood operation.
  • Cure the completed oven gradually according to the operating manual.

Manufacturer Resources

For model or installation assistance, contact Forno Bravo at (800) 407-5119.
