SKU: SBC683OS

Summit 24 Inch Outdoor Rated Kegerator with Solid Door

$2,400.00

Shipping calculated at checkout

Available Now!

Keep draft service close at hand with the Summit SBC683OS. This outdoor kegerator brings refrigerated keg storage to your serving area, with digital temperature controls.

Key Features

  • 1-tap dispensing package includes a tower, regulator, 5 lb. CO2 cylinder and American Sankey connections.
  • Cabinet accepts a half-barrel or quarter keg, or up to three sixth-barrel or Cornelius-style kegs; dispensing depends on the supplied tap count.
  • Removable drip tray helps contain serving spills.
  • Two removable chrome shelves let the cabinet also serve as beverage storage.
  • Four casters, including two locking casters, are supplied for optional mobile setup.

Specifications

  • Manufacturer: Summit Appliance. Model: SBC683OS.
  • Capacity: 5.6 cu.ft. (159 L).
  • Defrost: Automatic. Controls: digital.
  • Electrical rating: 115 V AC/60 Hz; 1.25 A.
  • Refrigerant: R600a.
  • Manufacturer temperature-setting range: 34°F to 68°F (1°C to 20°C).
  • Drawer/door finish: Stainless Steel. Cabinet: Stainless Steel.

Dimensions

  • Cabinet dimensions: 33.63" (85 cm) H × 23.75" (60 cm) W × 24.0" (61 cm) D.
  • Product weight: 120.0 lbs. (54 kg).
  • Depth including handle: 26.25" (67 cm).
  • Height with tap: 51.5" (131 cm). Allow space for the tower and its connections.
  • Cabinet dimensions are not a cutout specification. Allow the ventilation, opening and service space required by the linked manual.

Compatibility & Installation

  • Use a properly grounded, dedicated electrical outlet matching the rating label; have installation checked by a qualified professional.
  • Keep the front ventilation opening clear and position the appliance away from grills, ovens and other heat sources.
  • For built-in use, the manual specifies 3/16 inch at each side, 1/16 inch above and 2 inches behind.
  • Use a location within the manual’s 50–100°F ambient range, sheltered from wind, rain, water spray and drips.
  • For commercial use, confirm approval with Summit: the product page advertises commercial use or a commercial sanitation rating, but the linked manual restricts use to residential purposes.
  • R600a refrigerant is flammable. Protect the cooling tubing from damage and use authorized service personnel.
  • California warning: Summit identifies potential exposure to metallic nickel, a chemical California lists as causing cancer. See the manufacturer’s product notice and P65Warnings.ca.gov.

Manufacturer Resources

Contact Summit Appliance for model-specific installation and service assistance.
